HW-T2-40F Mini Desktop Pick And Place Machine For PCB Prototyping And Small-Batch SMT Assembly
HW-T2-40F mini desktop pick and place machine with 1,500-3,000 pcs/h speed, 0.05 mm accuracy, 40 feeder stations, only 76 kg. An affordable SMT assembler for PCB prototyping and small-batch assembly.
Product Introduction
The HWGC HW-T2-40F is a dual-head intelligent desktop pick and place machine weighing only 76 kg. It runs at 1,500-3,000 pcs/h with 0.05 mm accuracy, supports 40 feeder stations and handles 0201 up to 30x30 mm components - a cost-effective SMT assembler for PCB prototyping, R&D labs and small-batch assembly.
Key Features
- 2 placement heads, single-head pick and place
- 40 feeder stations (8 mm basis); electric, pneumatic and vibration feeders
- 2 IC trays, 20 positions
- Compact desktop design: 670x848x655 mm, 76 kg, easy to move
- Custom industrial-grade high-precision aluminum alloy frame
- Handles 0201-1206, LED beads, diodes, transistors, SOT up to 30x30 mm
- Components up to 7 mm height, Z-axis travel 22 mm
- One-click programming with coordinate file import
Specifications
| Placement Accuracy | 0.05 mm (repeatability 0.05 mm, positioning 0.01 mm) |
| Continuous Operation | more than 24 hours non-stop |
| Component Range | 0201-1206, LED beads, diodes, transistors, SOT, up to 30x30 mm; QFP/BGA (>0.3 mm pin pitch) within 50x50 mm; custom vision for irregular components |
| Nozzle Buffer | 4.5 mm, JUKI-compatible nozzles |
| Component Angle | +/-180 deg |
| PCB Thickness | 3 mm max (3-5 mm process edge required in auto mode) |
| Conveyor | default left-to-right, ESD belt, board sensor |
| Programming | import coordinate files, one-click auto programming, optimal path planning; CSV/TXT import |
| Control Host | Intel high-performance industrial PC, 17-inch industrial display |
| Drive System | high-speed DSP drive, AC servo motors |
| Vision | fixed-shot flying alignment; auto recovery of missed pickups, angle correction and reject |
| Model | HW-T2-40F |
| Placement Speed | 1,500-3,000 pcs/h |
| Feeder Stations | 40 (8 mm basis), YAMAHA CL compatible |
| IC Tray | 2 trays, 20 positions, 130x55 mm |
| Max Component Height | 7 mm (Z-axis travel 22 mm) |
| Placement Area | 310x230 mm (50x50 mm minimum) |
| Board Handling | manual loading/unloading |
| Air Supply | 0.4-0.5 MPa, external tank no less than 50 L with oil-water separation |
| Power | AC220V 50/60 Hz, 1500 W |
| Dimensions | L670 x W848 x H655 mm (packed: L770 x W950 x H750 mm) |
| Weight | 76 kg (packed: 96 kg) |
About HWGC
HWGC (Beijing Huawei Guochuang Electronic Technology Co., Ltd.) is a national high-tech enterprise integrating R&D, manufacturing and sales of SMT equipment. Founded in 2004 and pioneering domestic vision pick and place machines since 2010, HWGC offers four-head, six-head, eight-head and modular high-speed pick and place machines, together with reflow ovens (3/6/8 zones), screen printers, PCB separators and AOI, providing one-stop SMT production line customization for mass production, engineering samples and small-batch runs. With an R&D center in Beijing and a production base in Shijiazhuang, HWGC equipment is sold across China and exported to more than 60 countries, backed by ISO9001, CE and SGS certifications and multiple invention and utility model patents.
Key Advantages
- One-click intelligent programming: programming finished in about 5 minutes, saving up to 90% of programming time compared with traditional methods, supporting 24-hour non-stop production
- Automatic optimization of feeder station setup and nozzle assignment according to the BOM
- Multi-head simultaneous pickup and shortest-path automatic placement layout
- Automatic calibration of feeder pickup coordinates, saving about 30% of programming time
- Four-mark-point positioning and panel/combined-board function for higher efficiency
- Feeder anti-collision self-sensing system and three-stage scientific board conveying
- Custom vision solutions for irregular components
- Ceramic JUKI-compatible nozzles with 99.99% pick-up rate, wear-resistant and anti-static
- Gantry structure with XY linear guides, ball screws and AC servo drive for smooth, low-vibration motion
Warranty and After-Sales Service
- 1-year free warranty from the date of equipment training (excluding consumables and man-made damage)
- 2-hour response guarantee with phone or remote video support; on-site engineer dispatched within 48-72 hours when required
- Free on-site installation, commissioning and operator training
- Lifetime free software updates and upgrades
- Long-term supply of quality spare parts at favorable prices
