HW-T4-50F-PLUS SMT
The HW-T4-50F-PLUS is a four-head, high-speed, fully automatic SMT pick and place machine built by a professional China SMT machine manufacturer. Guided by an intelligent machine vision system, this chip mounter places surface mount components accurately onto the corresponding PCB pads, delivering the precision and throughput that modern PCB assembly demands. With a placement speed of 5,000-8,000 pcs/h and positioning accuracy of 0.01 mm, it fits smoothly into any SMT assembly line, from prototyping to round-the-clock production.
Key Features
- Four placement heads with dual-head simultaneous pickup for maximum placement throughput
- Placement accuracy of 0.05 mm and positioning accuracy of 0.01 mm for high-precision surface mount technology
- High placement speed of 5,000-8,000 pcs/h with non-stop operation beyond 24 hours
- Large placement area up to 320x190 mm (50F), supporting PCBs from 50x50 mm and up
- 50 feeder positions (8 mm feeder standard) with electric, pneumatic, vibration feeders and IC tray
- Advanced vision system: 1 mark camera, 4 high-speed recognition cameras and 1 high-precision camera
- Wide component range: 0201, 0402, 0603, 0805, 1206, LED beads, diodes, transistors, SOT, and QFP/BGA up to 30x30 mm
- Windows-based HWGC intelligent operating system with one-key automatic programming and CSV/TXT coordinate import
Technical Specifications
| Product Model | HW-T4-50F-PLUS |
| Placement Accuracy | 0.05 mm |
| Repeat Placement Accuracy | 0.05 mm |
| Positioning Accuracy | 0.01 mm |
| Continuous Working Time | Non-stop operation beyond 24 h |
| Placement Speed | 5,000-8,000 pcs/h |
| Placement Area (50F) | 320x130 mm with tray / 320x190 mm without tray; 50x50 mm minimum |
| Component Range | 0201, 0402, 0603, 0805, 1206, LED beads, diodes, transistors, SOT; QFP/BGA up to 30x30 mm with pin pitch over 0.3 mm; custom vision for odd-shaped components |
| Nozzles | 4 (JUKI compatible) |
| Component Angle | +/-180 degrees |
| Component Height | Max 7 mm |
| Simultaneous Pickup | Dual-head simultaneous pickup |
| Nozzle Buffer Range | 4.5 mm |
| Z-axis Maximum Stroke | 20 mm |
| Feeder Positions | 50 positions (8 mm feeder standard) |
| Feeder Types | Electric feeder, pneumatic feeder, vibration feeder, IC tray |
| Feeder Series | YAMAHA CL series compatible |
| IC Tray Quantity | 1 tray (48 positions) |
| IC Tray Size | L320xW150 mm |
| Loading Method | Automatic material optimization |
| Pickup Method | Manual / automatic |
| Board Thickness | Max 3 mm (3-5 mm process edge required in automatic mode) |
| Rail Adjustment | Manual / electric automatic adjustment |
| Conveying Mode | Left-to-right by default; supports both-side connection; single-stage board feeding |
| Conveyor Safety | Anti-static conveyor belt with board sensors |
| Vacuum Source | Vacuum generator (high-speed on/off vacuum breaking) |
| Vacuum Mechanism | Active-breaking high-speed high-flow vacuum generator |
| Air Pressure | 0.5-0.6 MPa |
| Air Supply Requirement | Oil-water separator; external air tank of at least 50 L with dust filter and pressure stabilizer |
| Operating System | Windows-based HWGC intelligent operating system (developed in-house) |
| Control Host | Intel high-performance industrial computer |
| Drive System | High-speed DSP drive with AC servo motors |
| Motion Safety System | Emergency stop button, tri-color alarm light, slowdown/stop when cover opened |
| XY Maximum Stroke | 440x570 mm |
| XY Guide Rail | Linear guide + rolled/ground ball screw (optional) |
| XY Motion Mode | Intelligent curve acceleration/deceleration with built-in linear interpolation |
| Motion Protection | High-wear-resistant drag chain and flexible cables |
| Recognition Devices | 1 mark camera, 4 high-speed recognition cameras, 1 high-precision camera |
| Display | 17-inch industrial control display |
| Imaging Method | Fixed-position flying centering |
| Recognition Method | 4 heads recognize and pick simultaneously |
| Mark Point Recognition | Manual / fully automatic positioning |
| Vision Safety Checks | Automatic correction of missed parts, automatic component angle correction, automatic rejection of invalid parts |
| Programming Method | Coordinate file import, one-key automatic programming, optimal path planning |
| Compatible File Formats | CSV / TXT direct import |
| Circuit Protection | Leakage protector, thermoset non-melting housing, crack-free quality interfaces, anti-leakage |
| Power Supply | AC 220 V, 50/60 Hz, 600 W |
| Dimensions (before packing) | L1250xW1300xH1300 mm |
| Weight (before packing) | 250 kg |
Applications
Suitable for all kinds of SMT production lines, the HW-T4-50F-PLUS handles PCB assembly for consumer electronics, LED lighting, automotive electronics and industrial control products. Its broad component range and flexible vision system also make it an excellent LED placement machine for LED lamp beads and display boards. Whether you are starting a new SMT assembly line or expanding an existing one, this fully automatic pick and place machine from a reliable China SMT machine manufacturer offers the accuracy, speed and stability your production needs.
