HW-T2-40F SMT
The HW-T2-40F is a dual-head, intelligent, high-speed, fully automatic SMT pick and place machine supplied by a China SMT machine manufacturer. Through machine vision, this compact chip mounter places surface mount components onto PCB pads with placement accuracy of 0.05 mm and positioning accuracy of 0.01 mm. With a placement speed of 1,500-3,000 pcs/h and a compact footprint of just 670x848 mm, it is a cost-effective entry point into PCB assembly for small and medium SMT production lines.
Key Features
- Dual placement heads with single-head pick-and-place motion for flexible placement
- Placement accuracy of 0.05 mm and positioning accuracy of 0.01 mm
- Placement speed of 1,500-3,000 pcs/h with non-stop operation beyond 24 hours
- Placement area of 310x230 mm, supporting PCBs from 50x50 mm and up
- 40 feeder positions (8 mm feeder standard), compatible with YAMAHA CL series feeders
- 2 IC trays (20 positions each) with tray size of L130xW55 mm
- Vision system with 1 mark camera and 1 high-precision camera, recognizing regular and odd-shaped components
- Compact desktop design: L670xW848xH655 mm and only 76 kg before packing
- One-key automatic programming with CSV/TXT coordinate file import
Technical Specifications
| Product Model | HW-T2-40F |
| Placement Accuracy | 0.05 mm |
| Repeat Placement Accuracy | 0.05 mm |
| Positioning Accuracy | 0.01 mm |
| Continuous Working Time | Non-stop operation beyond 24 h |
| Placement Speed | 1,500-3,000 pcs/h |
| Placement Area | 310x230 mm; 50x50 mm minimum |
| Component Range | 0201, 0402, 0603, 0805, 1206, LED beads, diodes, transistors, SOT; QFP/BGA up to 30x30 mm with pin pitch over 0.3 mm; custom vision for odd-shaped components |
| Nozzles | 2 (JUKI compatible) |
| Component Angle | +/-180 degrees |
| Component Height | Max 7 mm |
| Pickup Mode | Single-head pick and place |
| Nozzle Buffer Range | 4.5 mm |
| Z-axis Maximum Stroke | 22 mm |
| Feeder Positions | 40 positions (8 mm feeder standard) |
| Feeder Types | Electric feeder, pneumatic feeder, vibration feeder, IC tray |
| Feeder Series | YAMAHA CL series compatible |
| IC Tray Quantity | 2 trays (20 positions) |
| IC Tray Size | L130xW55 mm |
| Loading Method | Automatic material sequence optimization with guided loading |
| Pickup Method | Automatic pickup |
| Board Thickness | Max 3 mm |
| Rail Adjustment | Manual adjustment |
| Board Change Mode | Manual board loading/unloading |
| Carrier Structure | Customized industrial-grade high-precision aluminum alloy structure |
| Vacuum Source | Vacuum generator (high-speed on/off vacuum breaking) |
| Vacuum Mechanism | Active-breaking high-speed high-flow vacuum generator |
| Air Pressure | 0.4-0.5 MPa |
| Air Supply Requirement | External air tank of at least 50 L with dust filter, pressure stabilizer and oil-water separator |
| Operating System | Windows-based HWGC intelligent operating system (developed in-house) |
| Control Host | Intel high-performance industrial computer |
| Drive System | High-speed DSP drive with AC servo motors |
| Motion Safety System | Emergency stop button |
| XY Maximum Stroke | 320x527 mm |
| XY Guide Rail | Linear guide + rolled ball screw |
| XY Motion Mode | Intelligent curve acceleration/deceleration with built-in linear interpolation |
| Motion Protection | High-wear-resistant drag chain and flexible cables |
| Recognition Devices | 1 mark camera, 1 high-precision camera |
| Display | 17-inch industrial control display |
| Imaging Method | Fixed-position flying centering |
| Recognition Method | Regular component recognition and odd-shaped component feature recognition |
| Mark Point Recognition | Manual / fully automatic positioning |
| Vision Safety Checks | Automatic correction of missed parts, automatic component angle correction, automatic rejection of invalid parts |
| Programming Method | Coordinate file import, one-key automatic programming, optimal path planning |
| Compatible File Formats | CSV / TXT direct import |
| Circuit Protection | Leakage protector, thermoset non-melting housing, crack-free quality interfaces, anti-leakage |
| Power Supply | AC 220 V, 50/60 Hz, 1,500 W |
| Dimensions | L670xW848xH655 mm (before packing); L770xW950xH750 mm (after packing) |
| Weight | 76 kg (before packing); 96 kg (after packing) |
Applications
The HW-T2-40F is an ideal chip mounter for small-batch and flexible PCB assembly in SMT production lines, including consumer electronics, LED lighting, small appliances and development prototypes. Its ability to handle LED beads and odd-shaped components also makes it a practical LED placement machine for lighting manufacturers. As a fully automatic pick and place machine built on surface mount technology, it offers an affordable path into automated electronics manufacturing backed by a responsive China SMT machine manufacturer.
