HW-S100-460330
The HW-S100-460330 is a fully automatic PCB loader produced by HWGC, a China SMT machine manufacturer. This PCB handling equipment automatically feeds bare boards from a 460x400x565 mm magazine onto an SMT production line, and it can also be used as a quality sampling station. It accepts PCBs from 50x50 mm up to 460x330 mm with a thickness of 0.4-3.0 mm, storing up to 50 boards per full magazine load. Equipped with a Siemens dedicated PLC, a freely settable lift pitch of 10-50 mm and a transfer height of 900±20 mm, the loader provides dependable magazine-based feeding for PCB assembly lines that handle both small and medium boards.
Key Features
- Automatic magazine-based loading for PCBs from 50x50 mm up to 460x330 mm
- 460x400x565 mm magazine with 50-board full-load storage capacity
- Siemens dedicated PLC controller for stable, repeatable feeding cycles
- Lift pitch of 10, 20, 30, 40 or 50 mm, freely settable, with 1-5 step selection at 10 mm intervals
- Compact and energy-efficient: only 105 W startup and no-load power
- Front fixed edge as standard, rear fixed edge available on order
- Left-to-right transfer as standard, right-to-left available on order; transfer height 900±20 mm
- Anti-static conveying with 1500 VAC withstand voltage and 1000 Vp-p noise immunity
- Machine dimensions of 1450x860x1250 mm and weight of 150 kg
Technical Specifications
| Applicable Magazine Size | 460x400x565 mm |
| PCB Size | 50x50 to 460x330 mm |
| PCB Thickness | 0.4-3.0 mm |
| Magazine Size | 460x400x565 mm |
| Full-Load Board Storage | 50 boards |
| Machine Dimensions | 1450x860x1250 mm |
| Machine Weight | 150 kg |
| Power Supply | Single-phase 220 V |
| Startup Power / No-Load Power | 105 W |
| Lift Pitch | 10, 20, 30, 40, 50 mm, freely settable |
| Compressed Air | 5-6 kgf/cm2, 10 L/min |
| Fixed Edge | Front fixed (rear fixed available on order) |
| Transfer Direction | Left to right (right to left available on order) |
| Transfer Height | 900±20 mm |
| Pitch Selection | 1-5 steps (10 mm pitch) |
| High-Voltage Withstand | AC terminal to ground 1500 VAC, 1 minute |
| Operating Environment | Environment free of corrosive gases and dust |
| Anti-Interference | Voltage noise: 1000 Vp-p, pulse width 1 us, 1 minute |
| PLC | Siemens (dedicated controller) |
SMT Industry News
Smart factory and Industry 4.0 integration continues to spread across SMT lines, with MES connectivity, real-time process data and autonomous logistics becoming everyday requirements. In a connected line, every board movement matters: loaders that start, stop and step under PLC control give the MES system a predictable material flow to schedule against. Equipment like the HW-S100-460330, built around a Siemens dedicated controller, fits this model by offering deterministic magazine loading with settable pitch and direction. Factories adopting MES-driven production find that upgrading manual loading to automated board handling is one of the fastest ways to close the loop between planning systems and physical production.
Applications
The HW-S100-460330 fits the front end of SMT production lines running consumer electronics, LED driver boards, power supplies and small control boards. Its 460x330 mm board capacity covers both compact and mid-size PCBs, while the 50-board magazine supports extended unattended operation between magazine changes. As PCB handling equipment from a China SMT machine manufacturer, it pairs with solder paste printers, SPI inspection and chip mounters to keep the entire PCB assembly line supplied without manual board handling.
