HW-M12-102F SMT
The HW-M12-102F is a modular twelve-head high-speed SMT pick and place machine manufactured by HWGC (Huawei Guochuang), a professional China SMT machine manufacturer. This fully automatic pick and place machine places surface mount technology components onto PCB pads through precise machine vision, achieving a top placement speed of 22,000–33,000 pcs/h for high-volume PCB assembly. With 12 heads recognizing and picking simultaneously, flight centering vision, and 102 feeder positions, the HW-M12-102F is a high-output chip mounter for demanding SMT assembly lines, and it also serves as a fast LED placement machine for large LED lighting and display projects.
Key Features
- Twelve placement heads with multi-head simultaneous pickup and 12-head simultaneous flight centering recognition
- High precision: 0.05 mm placement accuracy, 0.05 mm repeatability, and 0.01 mm positioning accuracy
- Maximum placement speed of 22,000–33,000 pcs/h for high-volume PCB assembly
- Placement area of 350×370 mm without tray (350×115 mm with tray), minimum 50×50 mm
- 102 feeder positions (based on 8 mm feeders) with NXT feeder compatibility and JUKI nozzles
- Component height up to 20 mm, covering 0201 chips through tall odd-form components
- 2 IC tray slots (96 positions) with automatic material allocation and pickup coordinate positioning
- Over 24 hours of continuous non-stop operation with emergency stop, tri-color alarm lamp, and feeder lift alarm
Technical Specifications
| Model | HW-M12-102F |
| Placement Accuracy | 0.05 mm |
| Repeatability | 0.05 mm |
| Positioning Accuracy | 0.01 mm |
| Placement Speed | 22,000–33,000 pcs/h |
| Placement Area | 350×370 mm without tray / 350×115 mm with tray; minimum 50×50 mm |
| Component Range | 0201, 0402, 0603, 0805, 1206, LED beads, diodes, transistors, SOT, QFP/BGA up to 30×30 mm with lead pitch above 0.3 mm; custom vision available for odd-form components |
| Nozzles | 12 (JUKI-compatible nozzles) |
| Component Angle | ±180° |
| Component Height | ≤20 mm |
| Simultaneous Pickup | Multi-head simultaneous pickup |
| Nozzle Buffer Range | 4.5 mm |
| Z-Axis Maximum Stroke | 50 mm |
| Feeders | 102 positions (based on 8 mm feeders) |
| Feeder Type | Electric feeders, vibration feeders, IC trays |
| Feeder Compatibility | NXT feeders |
| IC Tray Slots | 2 trays (96 positions) |
| IC Tray Size | L330×W280 mm |
| Feeder Safety | Feeder lift alarm |
| Auto Loading | Automatic material allocation and automatic pickup coordinate positioning |
| Board Thickness | ≤3 mm (3–5 mm process edge required in automatic mode) |
| Track Adjustment | Manual / electric automatic adjustment |
| Transfer Mode | Left to right by default; both-side connection supported; three-stage board loading |
| Board Safety | Anti-static conveyor belt and board sensors |
| Vacuum Source | Vacuum pump |
| Vacuum Mechanism | High-speed vacuum break valve |
| Air Pressure | 0.5–0.7 MPa |
| Air Supply Requirement | Oil-water separator required; external tank of at least 60 L with dust filter and pressure stabilizer |
| Operating System | Windows-based, self-developed HWGC intelligent operating system |
| Control Host | Intel high-performance industrial PC |
| Drive System | High-speed DSP drive with AC servo motors |
| XY Maximum Travel | (Single side) 440×740 mm |
| XY Drive Guide | Linear guides + ground ball screws |
| XY Motion Mode | Intelligent curve acceleration/deceleration linear linkage with built-in linear interpolation |
| Motion Protection | High-wear-resistant drag chain and flexible cables |
| Safety System | Emergency stop button, tri-color alarm lamp, cover-open speed reduction/stop |
| Vision System | 1 mark camera, 12 high-speed recognition cameras, 1 high-precision camera |
| Display | 17-inch industrial control display |
| Imaging Mode | Fixed-shooting flight centering |
| Recognition Mode | 12 heads recognize and pick simultaneously |
| Mark Point Recognition | Manual / fully automatic positioning |
| Vision Safety | Missing-component auto correction, component angle auto correction, invalid part auto rejection |
| Programming Method | Coordinate file import, one-key auto programming, optimal path planning |
| Compatible File Formats | CSV / TXT direct import |
| Electrical Protection | Leakage protector, thermoset housing (non-melting, non-dissolving), high-quality anti-crack connectors |
| Power Supply | AC 220 V 50/60 Hz 1500 W |
| Continuous Operation | Over 24 hours non-stop |
| Dimensions (before packing) | L1920×W1510×H1450 mm |
| Dimensions (after packing) | L2000×W1680×H1640 mm |
| Weight (before packing) | 1300 kg |
| Weight (after packing) | 1400 kg |
Applications
The HW-M12-102F modular high-speed SMT pick and place machine is designed for electronics manufacturers that demand high throughput: LED lighting, LED displays, consumer electronics, power supplies, communication products, and high-mix SMT production lines. Its twelve heads, NXT feeder compatibility, and JUKI nozzles make this chip mounter easy to integrate into existing surface mount technology workflows, while one-key auto programming from CSV/TXT coordinate files shortens changeover time. As a China SMT machine manufacturer, HWGC offers this fully automatic pick and place machine factory-direct with worldwide shipping, technical training, and responsive after-sales support from our factory in Hebei, China.
