HW-S100-390530
The HW-S100-390530 is a fully automatic PCB loader from HWGC, a China SMT machine manufacturer. This PCB handling equipment feeds bare boards from a 535x460x565 mm magazine onto an SMT production line, and it can double as a quality sampling station for incoming inspection. It accepts PCBs from 50x50 mm up to 530x390 mm with a thickness of 0.4-3.0 mm, storing up to 50 boards per full magazine load. Driven by a Siemens dedicated PLC and consuming only 105 W, the loader steps boards down at a settable 10-50 mm pitch and transfers them at 900±20 mm, keeping medium-format PCB assembly lines continuously supplied.
Key Features
- Automatic magazine-based board loading for PCBs from 50x50 mm up to 530x390 mm
- Large 535x460x565 mm magazine with 50-board full-load storage capacity
- Siemens dedicated PLC controller for stable, repeatable feeding cycles
- Lift pitch of 10, 20, 30, 40 or 50 mm, freely settable, with 1-5 step selection at 10 mm intervals
- Energy-efficient operation with startup power and no-load power of only 105 W
- Front fixed edge as standard, rear fixed edge available on order
- Left-to-right transfer as standard, right-to-left available on order; transfer height 900±20 mm
- Anti-static conveying with 1500 VAC withstand voltage and 1000 Vp-p noise immunity
- Machine dimensions of 1550x920x1250 mm and weight of 170 kg
Technical Specifications
| Applicable Magazine Size | 535x460x565 mm |
| PCB Size | 50x50 to 530x390 mm |
| PCB Thickness | 0.4-3.0 mm |
| Full-Load Board Storage | 50 boards |
| Magazine Size | 535x460x565 mm |
| Machine Dimensions | 1550x920x1250 mm |
| Machine Weight | 170 kg |
| Power Supply | Single-phase 220 V |
| Startup Power / No-Load Power | 105 W |
| Lift Pitch | 10, 20, 30, 40, 50 mm, freely settable |
| Compressed Air | 5-6 kgf/cm2, 10 L/min |
| Fixed Edge | Front fixed (rear fixed available on order) |
| Transfer Direction | Left to right (right to left available on order) |
| Transfer Height | 900±20 mm |
| Pitch Selection | 1-5 steps (10 mm pitch) |
| High-Voltage Withstand | AC terminal to ground 1500 VAC, 1 minute |
| Operating Environment | Environment free of corrosive gases and dust |
| Anti-Interference | Voltage noise: 1000 Vp-p, pulse width 1 us, 1 minute |
| PLC | Siemens (dedicated controller) |
SMT Industry News
Demand for AI server boards and high-end computing PCBs continues to drive investment in SMT capacity worldwide. These dense, high-value boards put pressure on every stage of the production line, and manual board handling becomes both a bottleneck and a risk of costly damage. Automatic loaders that store boards in magazines and release them at a controlled pitch help factories run these demanding products continuously, protecting expensive boards while keeping placement equipment - usually the most expensive asset on the line - busy. For electronics manufacturers expanding capacity for computing, networking and data-center products, automated PCB loading equipment is becoming standard infrastructure rather than an optional extra.
Applications
The HW-S100-390530 is suited to the front end of SMT production lines that process mid-size boards: industrial control panels, network equipment, LED lighting drivers and consumer electronics mainboards. Its 530x390 mm board capacity and 50-board magazine make it a reliable feeder for solder paste printers, SPI stations and chip mounters in PCB assembly. As part of a complete SMT production line supplied by a China SMT machine manufacturer, it reduces labor at the line entrance and supports steady, unattended production runs.
