Pick and Place Machine Table
Computer control system
The SMT placement machine is generally equipped with computer monitor and mouse. It supports XP and Windows 7. It enables visual programming and PCB file import because of the humanized operating system.
Product Introduction
The HW-T4-44/50F is a highly efficient multifunctional intelligent machine designed specifically for research and development proofing businesses. With its diamond-grade technology, this cutting-edge machine is a real money saver, offering space saving features, low investment costs, high efficiency, and quick returns.
This machine is incredibly user-friendly, with an intuitive software operation guide that enables programming in just five minutes. The flash line change feature enables easy production plate changes without the need for blanking, making the system exceptionally efficient and agile. The intelligent replacement engineering further enhances the machine's efficiency, ensuring that it delivers outstanding performance at all times.
In terms of equipment parameters, the HW-T4-44/50F is built to the highest standards, delivering exceptional reliability, durability, and performance. Its high-speed cutting capabilities make it ideal for producing a wide range of products, from packaging materials to industrial components.
Overall, the HW-T4-44/50F is a truly exceptional machine that offers outstanding performance, efficiency, and versatility. It has been engineered to the very highest standards and has been rigorously tested to ensure that it delivers the outstanding results that businesses require. Whether you're in the research and development business or looking to improve your production processes, the HW-T4-44/50F is the perfect solution for all your needs.
SMT Table top Pick and Place Machine
Computer control system
The SMT placement machine is generally equipped with computer monitor and mouse. It supports XP and Windows 7. It enables visual programming and PCB file import because of the humanized operating system.
Automatic PCB loader
The SMT placement machine can directly put the printing finished PCB board onto the track to realize automatic board loading, aiming and placing and mounting. It supports multi-feeders: maximum 50 feeders. The size of standard IC tray, tube feeder, stick feeder can be adjustable.
Synchronous identification by four sets of cameras
The SMT placement machine is equipped with 6 cameras: one MARK, one high precision camera and 4 high-speed cameras. It can realize 4-head synchronous identification to ensure the speed and precision of mounting. The standard configuration is 16 JUKI high precision suction nozzles.
Servo system
The SMT placement machine is equipped with servo system imported from Panasonic, Japan with high precision and stability to ensure 24-hour stable mounting.
Chain
It adopts high pressure resistant and wear-proof drag chain which is the same type as the one of imported machines. The drag chain can bear thousands of times of proof pressure.
Track
It adopts high precision track from TBI Taiwan which has low noise and high precision to ensure the accuracy rate of BGA chips.
Conveyor
This SMT placement machine can be automatically connected to conveyor which can transport the PCB board to the SMT reflow soldering machine without manual assistant, thus saving labor cost.
Number of Placement Heads | 4(high-accuracy) |
Number of IC Trays | 48 |
Number of Feeders | 50/44(subject to 8mm feeder) |
Positioning Accuracy | 0.01mm |
Repeated Mounting Accuracy | 0.05mm |
Mounting speed range of resistance | 5000-8000Pcs/h capacitance components |
Applicable Components | resistor,capacitor,chip,lamp bead 0201-30*30mm etc. |
Supported Maximum Area of PCB | 50*50mm-(50F)350*190mm /(44F)350*260mm |
Feeders | electric feeder, pneumatic feeder,vibrating feeder, IC tray etc. |
Recognition Devices | mark camera x1,fast recognition camera x4, high-precision camera x1 |
Maximum Height of Applicable Components | ≤7mm |
PCB Convey Mode | three-stage entry,automatic connection from left to right, automatic PCB positioning |
Mark Positioning | manual / automatic |
Programming Method | automatic programming after manually importing files of PCB coordinates |
Control System | HuaweiGuochuang control system |
Maximum Step Length of XY Axis | 629mm*679mm |
Tracks of XY Axis | linear motion guide + Screw driver |
Motion Mode of XY Axis | intelligent linkage of acceleration and deceleration of curve and line, integrated linear interpolation algorithm. |
Control Computer | industrial control computer with Intel high-performance processor |
Adjusting Method of Tracks | electric |
Range of Nozzle Buffer | 4.5mm |
Maximum Step Length of Z Axis | 20mm |
Range of Angle for Components | ±180° |
Motor | AC Servo Motor series |
Driver | high-speed DSP driver |
Air Supply Requirements | oil water filter,≥ 50L,dust filter and air pressure stabilizer etc. |
Vacuum Supply of Nozzle | vacuum generator integrating the high-speed vacuum burst function |
Range of Air Supply Pressure | 0.5-0.7Mpa |
OS | Independent research and development SMT intelligent OS based on Windows |
PCB requires | 3-5mm process edge in automatic mode |
Vision Display | 17-inch industrial control display |
Cable | durable flexible cable(10 million times) |
Power Supply | 220V 50/60Hz |
Average Power | 600W |
Machine Dimensions | desk machine 1140*900*900mm |
Weight | (desk machine)210kg (vertical machine)280kg |
