HW-R816Z Reflow
The HW-R816Z is an eight-zone, tunnel-type SMT reflow oven from China SMT machine manufacturer HWGC, combining a 400 mm stainless steel mesh belt with a 280 mm rail for flexible board transport. It melts solder paste on PCB pads through forced hot-air convection. Sixteen heating zones, eight above and eight below the conveyor, run across a 2,800 mm heating section, followed by a 500 mm cooling section. Boards move at 0-1.8 m/min while PID plus SSR control holds ±1-2°C static accuracy up to 300°C for lead-free and leaded PCB assembly.
Key Features
- Nickel-chromium heating tubes with 4 μm peak radiation wavelength and curved reflectors
- Forced hot-air circulation heats mesh-belt and rail-carried boards evenly through the tunnel
- 120 kg per cubic meter rock wool insulation and stainless air-distribution plates for lead-free work
- Taiwan long-shaft high-temperature air motors with square heating tubes, modular and vibration-free
- Dual transport: 400 mm stainless mesh belt plus a 280 mm rail for framed panels
- Touchscreen control with microcomputer fuzzy-logic and PID temperature calculation
- Power-off protection with a mechanical return device and delayed shutdown for even cooling
Technical Specifications
| Product Model | HW-R816Z |
| Heating Zones | 8 upper, 8 lower |
| Heating Method | Hot-air circulation |
| Heating Zone Length | 2,800 mm |
| Cooling Zone Length | 500 mm |
| Conveyor Mesh Width | 400 mm |
| Rail Width | 280 mm |
| Conveying Direction | L-R (R-L optional) |
| Conveying Method | Mesh belt and rail |
| Conveyor Height | 900 ±20 mm |
| Conveyor Speed | 0-1.8 m/min |
| Temperature Control Accuracy | ±1-2°C static |
| Temperature Control Range | Room to 300°C, settable |
| Solder Types | Lead-free and leaded |
| Temperature Control Mode | PID plus SSR |
| Power Supply | 3-phase 380 V, 50 Hz |
| Startup Power | 40 kW |
| Working Power | 6 kW |
| Heat-up Time | Approx. 20 min |
| Dimensions | W4100 x D760 x H1350 mm |
| Net Weight | 800 kg |
| Temperature Profile System | 3-channel profiling |
| Machine Color | Computer white |
| Body Structure | Streamlined shell, 2 mm steel |
| Front and Rear Doors | Enclosed, magnetic catches |
| Upper Oven Opening | Dual-cylinder, self-lock |
| Top Cover Opening | Gas-spring, front opening |
| Surface Treatment | Anti-static, heat-cured |
| Heating Zone Quantity (heating section) | Independently switchable |
| Adjacent Zone Temperature Difference | Up to 100°C, lead-free |
| Heat-up Time (to thermal balance) | Approx. 20 min |
| Heat-up Sequence | Center-to-end sequence |
| Component Height Limit | 25 mm |
| Heating Zone Length (heating section) | 3,750 mm |
| Temperature Adjustment Range | 0-300°C |
| Heating Zone Control Accuracy | ±1-2°C static |
| Temperature Ramp-up Capacity | 3°C/s |
| Air Duct Structure | Independent upper/lower circulation |
| Independent Zone Shutdown | Per-zone PID, selective heating |
| Thermal Recovery Time | ≤0.5 s no-load to full-load |
| Hot-air Motor | Taiwan B and M, 2,800 rpm |
| Heating Elements | Taiwan Taizhan nickel-chromium |
| C/V Speed Range | 0-1,200 mm/min |
| C/V Speed Deviation | ±2% closed-loop |
| Conveyor Motor | Taiwan STK inverter motor |
| Conveying Method (transmission) | Mesh belt drive |
| Conveying Direction (transmission) | L to R (R to L optional) |
| Conveying Height | 900 ±20 mm |
| Mesh Belt Tensioning | Cartridge roller/sprocket |
| Mesh Belt | 400 mm 316# stainless |
| Control Host | 17-inch LCD computer |
| Control Interface | Windows |
| PLC and Temperature Modules | Siemens |
| Monitoring and Logging | Daily operation logs |
| Production Reports | Board-model database |
| Alarm List | Records alarms and analysis |
| Alarm Prompts | Light, buzzer, flashing UI |
| Temperature Profile Test | Saves profile data |
| Channel Real-time Monitoring | I/O and communication monitoring |
| Over-temperature Alarm | Independent over-temp circuit |
| Phase Sequence Protection | Phase-sequence protection |
| Upper Oven Opening (safety) | Pneumatic cylinder, self-locking valve |
| Communication Modules | Siemens CPU 224 CN, EM222/EM231/EM232 |
| Control Computer | Industrial PC, Celeron E1500 |
| Conveyor Motor and Gearbox | STK 90 W, 1:150 |
| Hot-air Motor Brand | Taiwan Sanyue |
| Chain | Imported 35B carbon steel |
| Intermediate Relays | OMRON |
| Inverter | Taiwan Zhongshu |
| Heating Wire | Taiwan Taizhan nickel-chromium |
| Photoelectric Switches | OMRON |
| Solid-state Relays | ANV |
| Air Switch / Main Switch | Chint |
| AC Contactors | Chint |
| Thermocouples | Insulated K-type, Taiwan Fanda |
| Push-button Switches | Schneider |
SMT Industry News
AI server boards and other high-end computing PCBs are driving strong demand for SMT capacity and high-precision placement equipment, and those boards are larger, thicker and harder to heat evenly. An eight-zone oven with independent upper and lower hot-air circulation, 3°C/s ramp capability and a 500 mm cooling section keeps the lead-free profile stable, while the mesh belt and 280 mm rail let one machine serve bare boards and panel carriers. Smart factory and Industry 4.0 integration is spreading across SMT lines too, so production reports, alarms and profile data can feed MES-level monitoring.
Applications
The HW-R816Z suits medium-volume PCB assembly in SMT production lines that need mesh-belt and rail transport in one footprint, including consumer electronics, LED lighting, power supplies, industrial control and appliance boards. The 280 mm rail carries framed panels and fixtured boards, while the 400 mm mesh belt covers standard bare boards with up to 25 mm component clearance. It is a flexible lead-free solder reflow oven for factories expanding PCB assembly capacity with equipment from a China SMT machine manufacturer.
